ThermTec Handheld Cyclone 625 25mm 50Hz

Cyclone 625 is a lightweight handheld thermal monocular built for close to mid-range observation. It features a 640×512, 12µm sensor with NETD <20mK for clear and stable imaging. With a detection range up to 1300m, it delivers reliable performance in the field. ThermTec AI Calibration enhances image stability, while multi-target ranging and fast startup support efficient operation.

Quality at a Value

Cyclone features a high-sensitivity NETD <20mK detector, providing sharp clarity in even challenging environments. Upholding ThermTec's commitment to quality, Cyclone now offers a more portable size and a more attractive price. Experience excellence that fits your needs.

Pocket-Sized Precision

With its compact size and ergonomically curved design, the device fits perfectly in your hand, enabling full control with one hand and effortless access to all buttons, regardless of whether you are left-handed or right-handed. The carefully arranged button layout allows for immediate usability once you take hold of it.

20 Hours Exploration

ThermTec's energy-efficient technology, combined with replaceable rechargeable batteries, ensures 10 hours of continuous operation. With two batteries, enjoy 20 hours of uninterrupted use from day to night. Plus, it supports use while charging—20 hours and beyond.

Consistently Clear & Stable Image

Cyclone utilizes progressive AI algorithms, making each use a process of machine learning. By collecting data from various environments, it ensures consistent and clear image quality under the same conditions.

3 Seconds to Boot

Simply press the power button while raising your hand to prepare for observation, and the device will quickly start up. Ensure you don't overlook anything you wish to explore.

Multi-target Distance Detection

Determining the distance to your target is essential for success. When multiple targets come into view, the Cyclone employs AI technology to automatically measure the distance to each heat source, greatly enhancing observation efficiency.

Tailored Viewing with 3 Modes

To accommodate the dynamic environmental conditions of targets, Cyclone features three modes—Forest, Target, and Outline—and six color palettes. You can customize the settings according to your current needs, enhancing observation efficiency while protecting your eyes during prolonged use.

More Advantages

• 0.39-inch AMOLED Display
• 6 Color Palettes
• -20?—+50? Operating Temperature
• IP67 Waterproof Rated

Specifications

• Resolution: 640x512@12µm
• Pixel pitch: 12µm
• NETD: 20mK@300K
• Spectral range: 8-14µm
• Frame rate: 50Hz
• Detection range: 1300m (Target height:1.8m)
• Objective lens: 25mm/F1.0
• Field of view: 17.5°×14°
• / m @100m: 30.8×24.6
• Magnification: 1.4X
• Digital zoom: 1X, 2X, 4X
• Eye relief: 20mm
• Exit pupil: 6mm
• Diopter: ±5D
• Type: AMOLED
• Display Resolution: 1024×768
• Display size: 0.39 inch
• Color palette: 6
• Image mode: Forest/Target/Outline
• Photo/video playback: Yes
• Language: Multiple-language
• Inbuilt Memory: 32GB
• PIP: Yes
• Heat Track: Yes
• OSD Recording: Yes
• Internal battery: Replaceable and rechargeable Li-ion battery (18650×1)
• Battery life: 8H
• Type-C: Battery Charge, Data transfer
• Hotspot: Yes, App remote control
• Working temperature: -20°C-+50°C
• Protection Level: IP67
• Weight, g: 261 (w/o battery)
• Dimension mm: 136(L)x76(W)x54(H)
• External Cable: USB cable
• Other Accessories: Lens cloth, charger, battery, etc.

Accessories Included:

• Monocular
• User manual
• USB cable
• Charger
• Lens cloth
• Lithium battery: 2
• Service and support card
• Box

For a replacement battery, click here.

Dimensions
