Guide TB650LS Apex Vision LRF 640x512 Thermal Clip-on

Clip-on Thermal Imaging Attachment. Precision in Silence, Clarity Without Lag

The TB LRF Series is a thermal clip-on tailored for hunting. It brings precision in silence while integrating multiple intelligent features into a compact, lightweight housing weighing under 490g: G-Zero shutterless technology, an in-lens LRF, the Hyper-light image enhancement algorithm, and the standard replaceable 18650 battery. It delivers unmatched downrange accuracy and exceptional handling convenience in the field.

Guide Sensmart’s next-generation thermal imaging solution that redefines the infrared core of outdoor optics from the ground up. Engineered for any condition, ApexVision delivers ultra-clear visuals with smooth, ghost-free motion, high-fidelity imaging, and razor-sharp detail at long range.

LRF in Lens. One Shot, One Hit: By integrating a precise 1200m laser rangefinder into the objective lens, TB 2.0 Series minimizes parallax error and reduces the device size - elevating ranging accuracy for precision shooting at any distance.

G-Zero Shutterless Design: The shutterless technology eliminates image freezing and reduces shutter calibration noise, ensuring silent, uninterrupted operation. (Note: The shutter module has been retained to ensure high image quality during startup and under significant temperature variations)

Ultra-Precise Zeroing 15x Optics Compatible: The TB 2.0 Series offers superior zeroing accuracy with 1.22cm@100m click adjustments. Compatible with daylight optics up to 15x magnification, it delivers exceptional shot-to-shot precision.

Replaceable Standard 18650: The TB 2.0 Series uses a standard 18650 battery that’s easy to purchase, replace, and recharge. The low-power design reduces power consumption, ensuring extended runtime for full hunting sessions.

Lightweight. Compact. Balanced: The palm-sized, compact device weighs only 485g*. Its well balanced design ensures even weight distribution when mounted to on a daylight scope, making the hunting gear easier to handle and more comfortable to use. *Note: weights differ across specific models.

6000J Recoil Resistance: The device features high reocoil resistance of up to 6000J. It ensures rock-solid, stable imaging under shooting recoil and maintains consistent accuracy with minimal point-of-impact shift.

Hyper-Light 2.0 Algorithm, Image Enhancement: The AI powered Hyper-Light 2.0 Algorithm, paired with an upgraded high-sensitivity thermal detector, delivers top-tier clarity with fine details, reduced noise, and optimized contrast.

Intelligent Functions

• Virtual reticle: overlays a virtual reticle in recorded videos to simulate real hunting scenarios.
• Smart recording: automatically records a 15-second video(with audio) and take 5 photos during shooting.
• Local album viewing: allows instant playback of recorded photos/videos directly on the device.

More Advantages

• 7 Colour palettes
• 2.4GHz/5GHZ WiFi
• Ballistic calculation
• IP68 Waterproof

Specifications

Sensor

• Core Technology Item Equipped with full ApexVision S1 system architecture: Detector ApexCore S1 + Platform Nexus 1.0 + Algorithm Hyper-Light 2.0
• Type Uncooled VOx Infrared Detector, 8 to 14µm
• Resolution 640×512@12µm
• NETD 15mK
• Frame rate 50Hz

Lens

• Objective lens 50mm, F0.9
• Field of view 8.8°×6.6°
• FOV m@100m 15×11
• Magnification 1x
• Detection range 2600m/2800yd
• Focus Manual

Display

• Display type 0.39'' AMOLED 1920×1080
• Color palettes White Hot, Black Hot, Red Hot, Green Hot, Iron Red, Blue Hot, Sepia
• Eyepiece Eye relief: 20mm

Hardware

• Laser rangefinder 1200m/1300yd
• WIFI 2.4G, 5G
• Interface USB-C (Power supply/USB2.0)
• Others Microphone, Bluetooth

System

• Recording function Photo/Video (Audio recording included)
• Memory capacity 64GB

Power

• Battery type Single, Replaceable 18650 Battery
• Operating time 5 hours

Environmental

• Operating temp. -20°C to 50°C / -4°F to +122°F
• Shock 6000J
• Encapsulation IP68

Physical

• Weight (g/oz) 485/17.11
• Size (mm/in) 139×86×79/5.47×3.39×3.11
• Standard Device, Carry Bag, Accessory Bag, Lint-Free Cloth, Battery Charger, 18650 Battery ×2, USB-A to USB-C Cable, Quick Start Guide, Warranty Card
• Optional Bluetooth Remote Control, Adapter Ring, 18650 Battery
