Guide TD635LS Apex Vision LRF Thermal Hand Held 35mm 640x512

Seize the Hunt

The TD Gen3 LRF Series handheld thermal imaging monocular innovatively integrates a laser rangefinder while maintaining a compact design. The focusing roller allows for convenient one-handed operation, while the symmetrical ergonomic design enables flexible handling with either hand. With an impressive 10-hour battery life and IP67, it is well-equipped to handle various outdoor challenges. Featuring Wi-Fi connection, it enhances the efficiency and enjoyment of your exploration.

Guide Sensmart’s next-generation thermal imaging solution that redefines the infrared core of outdoor optics from the ground up. Engineered for any condition, ApexVision delivers ultra-clear visuals with smooth, ghost-free motion, high-fidelity imaging, and razor-sharp detail at long range.

Easy Focus with Fingers: With just a simple finger scroll, the mini focusing knob allows users to quickly and precisely fine-tune focus.

Ambidextrous Design One-Hand Operation: The symmetrical housing design allows for easy operation with both left and right hands. Its button layout is ergonomically crafted to suit user habits, enabling one-handed operation.

ApexVision-Powered NETD <15mK: The TD Gen3 LRF Series features 12µm infrared detector with 640×512 and 400×300 resolutions, and offers 35mm lens, delivering impressively crisp images even in complete darkness.

Extended battery life, uninterrupted power: During observation, exploration and stalking in the field, the TD Gen3 LRF Series offers an impressive 10-hour runtime. The replaceable 18650 battery supports blind installation in the dark, with no need to distinguish between the positive and negative terminals.

Enlarged AMOLED Display Upgraded Vision: Building on the previous generation, the TD Gen3 LRF Series features a 0.49” AMOLED display with a 1280×960 resolution, delivering more vivid details and a more comfortable viewing experience.

Built-in LRF, precise target distance: The built-in laser rangefinder module is seamlessly integrated into the device design, enhancing portability and practicality, with a maximum range of 1200 meters for precise target location.

Video/Audio Recording Versatile Mobile App: With built-in storage of up to 64GB, users can freely record, store and sharing pictures, videos, and audio files without storage limitations.

More Advantages

• 2.4GHz/5GHz WiFi
• Multiple colour palettes
• All-day, all-weather
• OTA upgrade

Specifications

Sensor

• Core Technology Item Equipped with full ApexVision S1 system architecture: Detector ApexCore S1 + Platform Nexus 1.0 + Algorithm Hyper-Light 2.0
• Type Uncooled VOx Infrared Detector, 8 to 14µm
• Resolution 640×512@12µm
• NETD 15mK
• Frame rate 50Hz

Lens

• Objective lens 35mm, F1.0
• Field of view 12.5°×9.4°
• FOV m@100m 22×17
• Magnification 2.03x~16.24x
• Detection range 1800m/1950yd
• Focus Manual

Display

• Display type 0.49'' AMOLED 1440×1080
• Color palettes White Hot, Black Hot, Red Hot, Green Hot, Iron Red, Blue Hot, Sepia
• Eyepiece Eye relief: 20mm; Diopter: -6 to +6; Zoom: 13.8x

Hardware

• Laser rangefinder 1200m/1300yd
• WIFI 2.4G, 5G
• Interface USB-C (Power supply/USB2.0)
• Others Microphone, Bluetooth

System

• Recording function Photo/Video (Audio recording included)
• Memory capacity 32GB

Power

• Battery type Single, Replaceable 18650 Battery
• Operating time 10 hours

Environmental

• Operating temp. -20°C to 50°C / -4°F to +122°F
• Encapsulation IP67

Physical

• Weight (g/oz) 374/13.19
• Size (mm/in) 171×54×74/6.73×2.13×2.91
• Standard Device, Lint-Free Cloth, Carry Bag, Accessory Bag, Hand Strap, Neck Strap, Eye Mask, Battery Charger, 18650 Battery ×2, 5V 2A Adapter (US, UK, Australia, and Europe), USB-A to USB-C Cable, Quick Start Guide, Warranty Card
• Optional Bluetooth Remote Control, 18650 Battery

Warranty period on new thermal optics:

• Pulsar: 3 Year manufacturers warranty
• Guide: 1 Year + Register online and get an extra year: https://www.guideir.com/service/free-extended-warranty
• ThermTec: 3 Years manufacturers warranty
