Guide TB650 Pro 2.0 640x512 Clip On Thermal Scope with Laser Rangefinder

The TB 2.0 Series is a thermal clip-on tailored for hunting. It brings precision in silence while integrating multiple intelligent features into a compact, lightweight housing weighing under 490g: G-Zero shutterless technology, an in-lens LRF, the Hyper-light image enhancement algorithm, and the standard replaceable 18650 battery. It delivers unmatched downrange accuracy and exceptional handling convenience in the field.

Zero Shutter True Shutterless

G-Zero Shutterless Design brings a true zero-shutter experience during startup, eliminating image freezing that could cause missed targets or critical moments while aiming. It also reduces shutter calibration noise, ensuring silent, uninterrupted operation.

Note: The shutter module has been retained to ensure high image quality during startup and under significant temperature variations.

Hyper-Light Algorithm Smarter Clarity

The AI powered Hyper-light algorithm, paired with a high-sensitivity thermal detector, delivers top-tier clarity with fine details, reduced noise, and optimized contrast for long-range observation.

Standard 18650 Extended Runtime

For user convenience, the TB 2.0 Series uses a standard battery that’s easy to purchase, replace, and recharge. Each battery lasts up to 5 hours and is compatible with other Guide devices. The low-power design reduces power consumption, ensuring extended runtime for full hunting sessions.

Ultra-Precise Zeroing 15x Optics Ready

The TB 2.0 Series offers superior zeroing accuracy with ultra-precise 1.22 cm@100 m click adjustments. Compatible with daylight optics up to 15x magnification, it delivers exceptional shot-to-shot precision.

LRF in Lens. One Shot, One Hit

By integrating the laser rangefinder into the objective lens, TB650P 2.0 minimizes parallax error and reduces overall device size - elevating ranging accuracy for precision shooting or ballistic calculations at any distance.

Virtual Reticle Local Album Viewing

The TB 2.0 Series can overlay a virtual reticle in recorded videos to simulate real hunting scenarios, delivering an authentic and immersive experience. Its local album allows instant playback, sharing, and analysis of recorded photos/videos directly on the device.

Lightweight. Balanced Comfortable Handling

Weighing only 480~490g, the palm-sized device features a compact housing with smaller dimensions. Its well-balanced design ensures even weight distribution when mounted on a daylight scope, making the hunting gear easier to handle and more comfortable to use.

Specifications for Guide TB650 Pro 2.0 640x512 Clip On Thermal Scope with Laser Rangefinder:

Sensor

• Type: Uncooled VOx Infrared Detector, 8 to 14µm
• Resolution: 640×512@12µm
• NETD: 18mK
• Frame rate: 50Hz

Lens

• Objective lens: 50mm, F0.9
• Field of view: 8.8°×6.6°
• FOV m@100m: 15×11
• Magnification: 1x
• Detection range: 2600m/2800yd
• Focus: Manual

Display

• Display type: 0.39'' AMOLED 1920×1080
• Color palettes: White Hot, Black Hot, Red Hot, Green Hot, Iron Red, Blue Hot, Sepia
• Eyepiece: Eye relief: 20mm

Hardware

• Laser rangefinder: 1500m/1630yd
• WIFI: 2.4G, 5G
• Interface: USB-C (Power supply/USB2.0)
• Others: Microphone, Bluetooth

System

• Recording function: Photo/Video (Audio recording included)
• Memory capacity: 64GB

Power

• Battery type: Single, Replaceable 18650 Battery
• Operating time: 5 hours

Environmental

• Operating temp: -20°C to 50°C / -4°F to +122°F
• Shock: 6000J
• Encapsulation: IP68

Physical

• Weight (g/oz): 490/17.28
• Size (mm/in): 144×86×79/5.67×3.39×3.11
• Standard: Device, 18650 Battery ×2, Battery Charger, USB-A to USB-C Cable, Quick Start Guide, Warranty Card
• Optional: Bluetooth Remote Control, Adapter Ring, 18650 Battery
