InfiRay TL35V2 Thermal Scope 50Hz 35mm


In stock?

North Shore

Seen it cheaper elsewhere?

Request a Price Match - Click here.

Share this with your friends!


The InfiRay TL35 V2 is quite similar to it's predecessor, but it now has an upgraded OLED Sony display & new Microphone function to record your reaction!

The InfiRay TL35 Thermal Scope Tube series (BOLT in the US) is a cutting-edge thermal imaging riflescope, which has a similar appearance to the Day riflescope. A state-of-the-art design is made especially for professional hunters who value traditions and seek technological superiority.

Reticle instructions for the InfiRay TL35 Thermal Scope

V2 Features:

1.) TL35 V2 adopts a Sony 1024X768 OLED display instead of a 1280x960 LCOS display of TL35. The imaging quality is greatly improved compared to the LCOS display        & OLED will offer better layers and contrast.
2.) TL35 V2 is equipped with a Microphone function, therefore you record can your voice while taking a video.

3.) After the optimization, TL35 V2 can mute the operation of the controller.


High Image Quality:
The Tube Series is designed for faultless operation in extreme weather and temperature conditions. Whether or not   the environment is freezing cold or blistering hot, the image retains its contrast and vivid colors without loss of frame rate.

User-friendly Interface
Rotary knob offers smooth zooming while four navigation keys offer optimal feeling of control.

Picture-in-Picture Function
The Picture-in-Picture function improves accuracy by providing a 2x-magnified image of the reticle area at the top   of the display. It helps to zoom in on a target while maintaining visibility of the entire field of view.

Ultraclear Mode
Built-in Ultra-clear mode is designed for bad weather conditions, such as heavy fog and rain. It will make the Tube series more sensitive and capable of providing more details.

Reliable Full Aluminium Housing:
The Tube series housing is made of aluminum and is designed to improve reliability. Designed for rugged reliability, Tube riflescopes boast full and reinforced yet lightweight metal construction. Precision-fabrication of housing elements ensures flawless field performance.

Mounts on Standard 30mm Scope Rings:
Applicable for 30mm diameter Tube, the newly designed tubular appearance allows the Tube series to be installed in standard 30mm scope rings, with simple operation, stability and reliability.

Sufficient Operation Time and Flexible Battery Choice:
The working time of the built-in battery is up to 13 hours, and the replaceable 18500 battery will provide an additional 2.5 hours of operation.

Extreme Detection Range:
The combination of the advanced thermal imaging sensor and the high-quality germanium optical lens provides an unprecedented detection range of up to 1800 meters, even in complete darkness.

12μm Pixel Pitch:
A high-performance detector with a pixel pitch of 12μm.

Built-in Video Recorder and WiFi Connection:
32 GB internal storage provides 48 hours of video recording capability, or approximately 40,000 images of photo storage. WiFi mode allows for up to 4 connections simultaneously.

• Detector Resolution: 384 x 288
• Pixel Pitch: 12μm
• NETD: ≤40 mK
• Frame Rate: 50 Hz
• Objective Lens: 35 mm
• Field of View: 7.5° × 5.6°
• Magnification:  3.0 - 12.0x
• Eye Relief: 70 mm
• Diopter Adjustment: -4D | +4D
• Display Resolution: 1024 x 768p OLED
• Battery:  bulit-in 18650
• External Battery: 18500
• Max. Battery Life: 15 h
• Amount of built-in memory: 32 gb
• Weight (without batteries-18500): <950 g
• Dimension: 385 x 85 x 75 mm
• Interface: Type-C
• Detection Range (Target size: 1.7 m×0.5 m, P(n) = 99%):  1816 m
• Microphone Yes


View the product manual here


Warranty period on new thermal optics:
Pulsar: 3 Year manufacturers warranty
Guide: 1 Year + Register online and get an extra year:
InfiRay: 2 Year warranty:

Please note: Manufacturers warranty period above covers the unit itself and does not cover commercial use. Thermal accessories will have a lesser cover period that what is specified for the units above. The warranty does not cover mis-use or accidental damage caused by the operator.
