Embark on nighttime explorations with the TJ LRF Series, a top pick for hunters. Equipped with exceptional thermal imaging technology, this device features a high-sensitivity infrared detector that enables clear night vision. The Full-HD display enhances these benefits, while two-hand operation, laser ranging, video recording, and a 12-hour battery life make it the perfect companion for nighttime escapades.

This Thermal imaging unit runs with 18650 Button top type batteries (174169) or (454065)

Key Features:

• 640x512
• NETD<20mK Detector
• Full-HD 1920x1080 AMOLED display
• up to 1000m Laser range
• IP67 Encapsulation

Welcome to the big screens. TJ LRF Series - Handheld Thermal Imaging Monocular

12um high sensitivity infrared detector

By utilizing a highly sensitive IR detector with a NETD<20mK, even the slightest temperature differences, can be distinguished resulting in sharper and clearer imaging.

1920 X 1080 AMOLED Display

The eyepiece features a 1920x1080 high-definition AMOLED screen, allowing for a visual experience with vibrant colors and excellent image quality. This significantly enhances the comfort of observation.

25/35/50mm F1.0 focal length

Multiple focal lengths give TJLRF Series stronger capabili-ties and more options in dif-ferent environments. The maximum 50mm F1.0 lens can clearly indicate targets within 2000m, which is convenient for observation and recording.

1000m laser ranging

The built-in laser rangefinder provides a long detection range up to 1000m, improving the capability to obtain the target distance and the long-distance perception.

Specifications:

Sensor

• Type Uncooled VOx Infrared Detector, 8 to 14 µm
• Resolution 640×512@12µm
• NETD 20mK
• Frame rate 50Hz

Lens

• Objective lens 50mm, F1.0
• Field of view 8.8°×6.6°
• FOV m @100m 15×12
• Magnification 3.79x~30.32x
• Detection range 2600m/ 2800yd

Display

• Display type 0.39'' AMOLED 1920x1080
• Color palettes White Hot, Black Hot, Red Hot, Green Hot, Iron Red, Blue Hot, Sepia
• Eyepiece Exit pupil distance 16 mm; Diopter: -6 to +6; Zoom: 18x

Hardware

• Laser rangefinder 1000m/ 1090yd
• WIFI 2.4G, 5G
• Interface USB Type-C (Power supply/USB2.0)
• Others Microphone, Compass, Gyroscope, Bluetooth

System

• Recording function Photo/Video (Audio recording included)
• Memory capacity 64GB

Power

• Battery type 2 replaceable 18650 batteries
• Operating time 10 hours

Environmental

• Operating temp. -20 °C to 50 °C/ -4°F to +122°F
• Encapsulation IP67

Physical

• Weight(g/ oz) 625/ 22.05
• Size(mm/ in) 243×97×66/ 9.57×3.82×2.60
• Standard A device, Wrist strap, Battery charger, 18650 battery×2, 5V2A adapter (US, Britain, Australia and Europe), USB Type-C cable, Quick use guide, Warranty card
• Optional Bluetooth remote control, 18650 battery

Warranty period on new thermal optics:

• Pulsar: 3 Year manufacturers warranty
• Guide: 1 Year + Register online and get an extra year: https://www.guideir.com/service/free-extended-warranty
• ThermTec: 3 Years manufacturers warranty

Please note: Manufacturers warranty period above covers the unit itself and does not cover commercial use. Thermal accessories will have a lesser cover period that what is specified for the units above. The warranty does not cover mis-use or accidental damage caused by the operator.
