Guide TB650-Pro-LRF 50mm 640x512 50hz Thermal Clip-on Scope Laser Rangefinder

Guide TB650LP | Laser Range Finder | Thermal Imaging Scope Clip-on Attachment

After an in-depth hardware upgrade and software optimization, the TB LRF Pro Series combines precision and portability. Its appearance remains light without reducing professionalism at all: built-in laser rangefinder can reach an ultra-long distance of up to 1,000 meters; two batteries empower a longer operating time; the full HD AMOLED display brings a rich and detailed visual experience; it also supports intelligent functions such as image tracing, automatic recording, AI tracking, etc.

Features:

• 12um infrared detector: TB LRF Pro Series adapts the high-sensitive 12um infrared detector with NETD down to 20mK. The advanced detector can distinguish the slightest differences and changes in temperature.
• 1000m laser rangefinder: The built-in LRF module provides a long laser rangefinder of up to 1000m, enabling users to detect and locate the targets quickly and precisely.
• FuII-HD 1920x1080 AMOLED display: TB LRF Pro Series is equipped with a 0.39" AMOLED 1920x1080 display screen, presenting a vivid image with more details for users.
• IP68 dustproot & waterproof: Compact and rugged, portable and powerful, the TB LRF Pro Series shares the high protective features of lP68, to support your outdoor adventures in the harsh environment.

Specifications

Sensor

• Type Uncooled VOx Infrared Detector, 8 to 14 µm
• Resolution 640×512@12µm
• NETD 20mK
• Frame rate 50Hz

Lens

• Objective lens 50mm, F1.0
• Field of view 8.8°×6.6°
• FOV m @100m 15×12
• Magnification 1x
• Detection range 2600m/ 2800yd

Display

• Display Type 0.39'' AMOLED 1920x1080
• Color palettes White Hot, Black Hot, Red Hot, Green Hot, Iron Red, Blue Hot, Sepia
• Eyepiece Exit pupil distance 20mm; Zoom: 6.8x

Hardware

• Laser Range Finder: 1000 m / 1090 Yards
• WIFI 2.4G, 5G
• Interface USB Type-C (Power supply/USB2.0)
• Other: Microphone, Bluetooth

System & Power

• Recording function Photo/Video (Audio recording included)
• Memory capacity 64GB
• Battery type: 2 18650 batteries
• Operating time: 9 hours

Environmental & Physical

• Operating temp. -20 °C to 50 °C/ -4°F to +122°F
• Shock 1000 G at 1 ms half sine pulse (as per IEC60068-2-27)
• Encapsulation IP68
• Weight(g/oz) 582/ 20.53
• Size(mm/in) 161×89×97mm / 6.34×3.50×3.82"

Includes in Box...

• A device,
• Battery charger,
• 18650 battery×2,
• 5V2A adapter (US, Britain, Australia and Europe),
• USB Type-C cable,
• Quick use guide,
• Warranty card
