Guide TB360 Thermal Imaging Attachment 640x480

Discover the Guide Sensmart TB630: Innovative thermal imaging attachment at an unbeatable price! With an impressive infrared resolution of 640×480 pixels and a highly sensitive VOx detector, the TB630 provides a detailed representation of thermal images at a competitive price. With a thermal sensitivity of less than or equal to 20mK (NETD), even the finest temperature differences can be detected, making it invaluable in various applications from hunting to surveillance.

A frame rate of 50Hz ensures clear moving images, ideal for situations with fast movements. The thermal images are displayed on a high-resolution 1920×1080 pixel AMOLED display, known for its brilliant image quality and low power consumption.

The TB630 is equipped with a 35mm/F1.0 lens that allows manual focusing and, combined with 1x optical magnification, offers a wide field of view of 21.8x16.4 meters at 100 meters distance. The detection range of up to 1,400 meters enables the identification of distant objects.

With a startup time of less than 3 seconds, the device is quickly ready for use, while the swappable battery system provides a runtime of more than 10 hours. With compact dimensions of 128x79x79mm and a weight of only 440 grams, the TB630 is mobile and handy. Support for photo and video recording, as well as OTA software updates through the TargetIR App, complete the offering.

The Guide Sensmart TB630 provides a technologically advanced solution for users seeking a powerful thermal imaging attachment with excellent image quality without compromising on the price-performance ratio.

To fit to a standard scope requires an adjustable lens adapter; Guide TA/TB Thermal Lens Adapter

Features:

• Thermal sensitivity of NETD<20mK for even clearer images and more details
• Durable, robust housing yet compact
• 18650 replaceable batteries with approximately 10 hours of runtime
• Startup time of less than 3 seconds

Specifications:

• Sensor: 640×480 Pixel IR
• Sensor Technology: VOx Detector
• Display: 1920×1080 Pixel
• Display Technology: AMOLED
• Detection Distance: 1,400m
• Field of View at 100m: 21.8×16.4 Meters
• Battery Runtime: = 10h
• Battery: 18650
• Sensitivity (NETD): = 20mK
• Pixel Pitch: 12µ
• Frame Rate: 50Hz
• Lens Focal Length: 35mm/F1.0
• Optical Magnification through the Lens 1x
• Recording: Photo / Video
• WLAN / Wifi / App: Yes
• Weight: 440 Grams
• Size: 128x79x79mm

Please Note: The adapter & firearm package is not included
