Browning T-Bolt Stainless Synthetic 22" with Varmint Barrel | 22 or 17HMR

A marriage between speed and accuracy.

T-Bolt. The return of a legendary rimfire. We all remember the first time squeezing a trigger, usually consisting of simply plinking a few tin cans. For some of us, those first shots were from an original Browning T-Bolt, one of the most accurate, handy and easy-to-shoot rimfires ever produced. Those days can now be relived with today’s T-Bolt, a rifle every bit the equal of the original, with new features that put this unique rifle in a class by itself.

The straight T-Bolt design lets you load and eject with a simple pull back and push forward. This system is unequaled among rimfires for raw bolt action speed — nearly as fast as a semi-auto 22. But you retain all the accuracy advantages of a bolt action design. Todays T-Bolt has even more than the original.

Double Helix. When you use the classic straight-pull bolt-action design to chamber each cartridge they are fed from the new 10-round rotary Double Helix™ (patent pending) box magazine. No magazine is like the Double Helix. And no magazine is easier to load and more reliable at feeding.

Three lever trigger accuracy. The T-Bolt’s three-lever trigger offers a light, crisp break, and every barrel is free floating. For those of you who are serious about rimfire accuracy will appreciate the new T-Bolt Target/Varmint model. It features a walnut stock with raised Monte Carlo comb and a heavy varmint barrel designed to provide pinpoint accuracy that rivals many custom rimfires costing much more.

Features:
• Stock: Target/Varmint models feature a Monte Carlo comb and wide forearm for stability on the bench. Standard T-Bolt is a sporter stock configuration. Both include dual action screws.

• Action: Receiver is machined from steel barstock. Features a classic crossbolt lockup, with an enlarged bolt handle pivot point moved forward for smoother action. Mainspring runs directly through the massive pivot pin. Cocking effort is split between opening and closing for ease of operation. One-piece dual extractor with integral spring and red cocking indicator band.

• Trigger: Lightweight gold-tone trigger, black trigger guard and housing. The three-lever trigger design combined with a short-travel firing pin gives a crisp break, quick lock time, no take-up and minimal overtravel. Externally adjustable for pull weight.

• Safety: Top-tang, thumb operated two-position safety can be operated without changing from a shooting grip.

• Barrel: Target/Varmint model features a 22 heavy varmint profile. T-Bolt Sporter features a 22 medium sporter profile. Both are free-floating and have a semi-match chamber and target muzzle crown.

• Sights: Receiver is drilled and tapped for scope mounts (scope not included).

• Magazine: Patent pending Double Helix™ rotary box magazine. 10-round capacity. Easy to load and unload and perfect alignment with the chamber every time. This innovative design makes other rotary magazine designs look clunky and bulky.

Specifications:
• Calibre: 22 LR | 17HMR
• Magazine Type: Double Helix
• Magazine Capacity: 10 rounds
• Barrel Length: 559 mm | 22"
• Trigger: Adjustable three-lever
• Stock: Synthetic
• Safety: Top-tang thumb
• Finish: Stainless
• Overall Length: 1022 mm / 40.25"
• Weight: 2.1 Kgs | 2.4 Kgs
• Rate of Twist: 1:16" | 1:9"
• Length of Pull: 343 mm | 13.5"

Other Specifications:
• Drop at Comb 5/8"
• Drop at Heel 5/8"
• Barrel Finish: Satin Blued
• Stock Finish: Matte Black
• Chamber Finish: Polished
• Barrel Material: Steel
• Receiver Material: Steel
• Trigger Material: Alloy
• Trigger Finish: Gold Plated
• Trigger Guard Material: Synthetic
• Drilled and Tapped for Scope: Yes
• Recoil Pad Plastic Butt-plate with Magazine Storage Compartment
• Checkering Textured Grip Panels
• Sling Swivel Studs: Gloss Stainless

Purchase of this item requires a firearms licence, you will need to complete a Police Order Form and take it into your local police station to have it signed off. The form can be found from the link below.
