Osight Red Dot R Micro T1/T2 Footprint with Multi-Reticle System

Features

• Large Field of View with Multi-Coated Lens: Featuring a 1.10" × 0.87" window and multilayer lens coatings, the Osight R delivers a brighter, wider sight picture for faster target acquisition and transitions.
• Multi-Reticle System: Switch between a precise 2 MOA dot, a bold 65 MOA circle, or both to balance speed and precision across different shooting scenarios.
• Protective Lens Covers with ARD Compatibility: Removable front and rear protective lens covers shield the primary glass from debris, scratches, and impact. The front cover can be replaced with the included anti-reflective device (ARD) to reduce glare and reflections.
• Micro T1/T2 Footprint: Built on the widely adopted Micro T1/T2 footprint, Osight offers 1.21?, 1.535?, and 1.93? optical center height mounting options, allowing the optic to adapt to a wide range of setups and shooting preferences.
• Quick-Access NV Button: An NV button enables convenient switching between daylight and night vision modes. With 9 daylight and 3 night vision settings, each mode retains its last-used level for quick adjustment and consistent visibility.

Square View, More in Sight

The expensive 1.10" x 0.87" square viewing window opens up the sight picture, keeping more of the scene visible.

True Clarity. True Colour

Precisely tuned multilayer coatings maximize clarity while minimising colour shift, delivering a bright, crisp view with natural colour.

Multi-Reticle System

Choose the 2MOA dot for precision, the bold 65MOA circle for speed, or both for maximum versatility.

Protect Your View. Cut the Glare

Removable covers protect against impact, scratches, and debris. Swap in the included ARD to reduce glare and reflections.

Micro T1 / T2

Compatible with the widely adopted Micro T1/T2 footprint, with 1.21", 1.53", and 1.93" mount heights to fit a wide range of setups and shooting preferences.

Instant DL / NV Switching

An NV button enables convenient switching between daylight and night vision modes, eliminating the need to cycle through brightness settings.

Ready When You Move

Featuring Motion Activation Technology (MAT), the Osight R powers on with the slightest movement and powers down after 3 minutes of inactivity to conserve battery. With Low Power Indication, when the battery voltage drops below 2.2V, the reticle quickly triple-flashes once per minute to recommend a battery replacement.

Strength in Every Detail

The 7075-T6 aluminum housing provides recoil and impact resistance, while the IPx8 rating supports reliable performance in wet conditions.

Championships Proven

Engineered for elite competition. Proven by champions on the line. Osight R helped power the Osight Pro Team to podium finishes and match victories at the 2026 USPSA Race Gun Nationals.

Flexible Mounting Heights

Osight R includes a 1.53" lower 1/3 co-witness mount, with optional 1.21" low (ORL-121) and 1.93" high (ORH-193) mounts sold separately to fit your preferred setup.

Technical Specifications

MATERIALS

• Optic Material: 7075-T6 Aluminum

GENERAL DATA

• Light Wavelength: 650nm
• Magnification: 1×
• Max. Runtime: 83,000 H (Mode 5)
• Memory Function: Yes
• Motion Sensor Function: Yes
• Multi-Coatings: Yes
• Parallax Free: Yes
• Reticle Color: Red
• Reticle Type: 2 MOA Dot & 65 MOA Circle
• Unlimited Eye Relief: Yes
• W&E Travel Range: ± 50 MOA
• Window Size: 1.10 × 0.87 in (28× 22 mm)
• Torque Specification: M3 12in-lbs Per Screw M5 43in-lbs Per Screw
• Brightness Settings: 9 DL & 3 NV
• Adjustment: 0.5 MOA per click
• Power Source: CR2032

TECHNICAL CHARACTERISTICS

• Waterproof: IPX8
• Weight: 6.70 oz (190 g) (standard mount & battery included)
• Packaging: Carton Box
• Use: Tactical, Competition, Training, Hunting
• Dimensions (Length x Width x Height): 2.72 × 1.42 × 2.52 in (69 × 36 × 64 mm)
• Working Temperature: -22°F to 140°F (-30°C to 60°C)
• Storage Temperature: -40°F to 158°F (-40°C to 70°C)

ENVIRONMENT SPECS

• Vibration: 1000G

PACKAGE CONTENTS

• Optic (CR2032 battery included) × 1
• Lower 1/3 Co-Witness Mount (ORS-153) × 1
• Adjustment Tool × 1
• READ ME Card × 2
• Protective Lens Covers× 2
• Osight R Screw Kit × 1
• ARD (Anti-Reflective Device) × 1
• Cleaning Cloth × 1
• Safety Warnings × 1
• User Manual × 1
• Osight Sticker × 1
