Guide TE425S ApexVision Thermal Handheld 25mm 400x300

The Guide TE Series Handheld Thermal Imaging Monocular is a pocket-sized night vision powerhouse, offering exceptional performance at an affordable price. It is equipped with a highly sensitive infrared detector, providing multiple resolutions and lens options to meet your diverse needs in various environments. A 10-minute quick charge gives you an hour of continuous use, making it the perfect companion for your outdoor explorations.

Key Features

• IP67 Waterproof
• Smooth Operation
• Pocket-sized
• 400x300/256x192

Featuring a 400×300 @12µm thermal sensor with<15mK NETD sensitvity and a 25mm lens with a 1300m detection range, the Guide TE425S Handheld Thermal Imaging Monoculadelivers clear thermal imagery and reliable long-range detection.

Powered by the advanced APEXVISION image processing system, it enhances image clarity and detail for confident viewing in demanding conditions. A 10-minute fast charge provides up to one hour of continuous operation, making the TE Series the perfect lightweight companion for hunting, wildlife observation, security, and outdoor adventures.

• 400×300@12µm IR resolution
• Ultra Lightweight - Only 320g
• One-button control for smooth operation
• IP67 IP rating

COMPLETE APEXVISION S1 SYSTEM ARCHITECTURE

The Guide TE425S is powered by Guide’s next-generation thermal imaging solution. ApexVision redefines the infrared core of outdoor optics from the ground up – engineered for any condition, it delivers ultra-clear visuals with smooth, ghost-free motion, high-fidelity imaging and razor-sharp detail at long range.

Powerful 12µm detector, Sharp image quality

To achieve a crisp image clarity, the TE Series is equipped with a powerful 12µm detector and offers multiple resolutions and lenses to meet your needs in various scenarios and activities.

Ultra-lightweight, Effortlessly portable

The TE Series only weighs over 200 grams with a compact, pocket-sized design, small like a mobile phone and thinner than a wristwatch, offering a comfortable grip and exceptional portability.

Smooth operation, One-button, one-ring

Based on years of outdoor experience, the TE Series has streamlined the button design to simplify operations. With a one-button and one-ring design, you can easily access the menu and perform various functions, allowing for seamless control.

Extended battery, 20W quick charge

The TE Series integrates a built-in rechargeable battery that provides up to 6 hours of runtime. It features an advanced 20W quick charge function. With just 10-minute quick charging, you can enjoy 1 hour of continuous use, ensuring worry-free power.

Comfortable viewing, Clear and smooth visuals

The 0.32-inch AMOLED screen presents rich colors and clear, smooth images, offering top-notch visual effects. The comfortable eyepiece and 25mm eye relief reduce eye fatigue, providing a great visual experience for your outdoor observation activities.

Audio-visual sync

Photos, videos, and audio recordings are all available. With 16GB built-in storage, you can flexibly capture and share exciting moments in the wild anytime and anywhere.

Dual-band, WiFi connection

The WiFi function has been upgraded to dual-band, providing stronger connectivity. The TE Series features faster transmission speeds and longer distances, with upgrade packages downloading in just 10 seconds and a maximum transmission distance of 26.5 meters.

Specifications

Sensor

• Core technology: Equipped with full ApexVision S1 system architecture: Detector ApexCore S1 + Platform Nexus 1.0 + Algorithm Hyper-Light 2.0
• Type: Uncooled VOx Infrared Detector, 8 to 14µm
• Resolution: 400×300@12µm
• NETD: 15mK
• Frame rate: 50Hz

Lens

• Objective lens: 25mm, F0.9
• Field of View: 11.0°×8.2°
• FOV m@100m: 19×14
• Magnification: 1.9x~7.6x
• Detection range: 1300m/1400yd
• Focus: Manual

Display

• Display type: 0.32'' AMOLED 800×600
• Color palettes: White Hot, Black Hot, Red Hot, Green Hot, Iron Red, Blue Hot, Sepia
• Eyepiece: Eye relief: 25mm; Diopter: -5 to +5; Zoom: 13.8x

Hardware

• Wi-Fi: 2.4G, 5G
• Interface: USB-C (Charging/Power supply/USB2.0)
• Others: Microphone, Bluetooth

System

• Recording function: Photo/Video (Audio recording included)
• Storage capacity: 64 GB

Power

• Battery type: Built-in Battery
• Operating time: 5 hours (Support 20W quick charging)

Environmental

• Operating temp.: -20°C to 50°C / -4°F to +122°F
• IP Rating: IP67

Physical

• Weight (g/oz): 320/11.29
• Size (mm/in): 157×51×47/6.18×2.01×1.85
• Standard: Device, Wrist Strap, Carry Bag, Lint-Free Cloth, USB-C to USB-C Cable, Quick Start Guide, Warranty Card
• Optional: Bluetooth Remote Control, Quick Charging Adapter, USB-A to USB-C Cable
